Khawla Flanges, located in Muscat, Oman, stands out as a top manufacturer and supplier of premium DIN 2635 PN40 Weld Neck Flanges. These flanges are crafted to meet rigorous international and European standards. Renowned for their precision, durability, and ability to handle pressure reliably, they are made using cutting-edge manufacturing techniques and strict quality control measures. Khawla Flanges is dedicated to providing trustworthy solutions for challenging industrial settings, ensuring exceptional performance and longevity. With a talented technical team and state-of-the-art facilities, the company offers customized flange solutions tailored to meet specific customer needs, making it a preferred supplier across various sectors.
DIN 2635 PN40 Weld Neck Flanges are crafted from high-quality carbon steel or alloy steel, depending on the specific application. Their composition generally includes carbon, manganese, silicon, and carefully controlled alloying elements to boost strength and temperature resistance. These flanges showcase impressive tensile and yield strength, along with high pressure resistance and consistent mechanical performance even at elevated temperatures. Their sturdy weld neck design promotes even stress distribution, reducing fatigue and enhancing long-term reliability. Each flange goes through rigorous dimensional checks, material testing, and pressure testing to ensure they meet DIN standards and maintain superior operational integrity.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Pipe | Flange | Neck | Raised face | Screws | Weight | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (7,85 Kg/dm3) | ||||||||||||||||
| Rated | d1 | D | b | k | h1 | d3 | s | r | h2 | d4 | f | Holes | Thread | d2 | Kg | |
| Diameter | ISO Series | DIN Series | ||||||||||||||
| 15 | – | 20 | 95 | 16 | 65 | 38 | 30 | 2 | 4 | 6 | 45 | 2 | 4 | M 12 | 14 | 0,746 |
| 21,3 | – | 32 | ||||||||||||||
| 20 | – | 25 | 105 | 18 | 75 | 40 | 38 | 2,3 | 4 | 6 | 58 | 2 | 4 | M 12 | 14 | 1,06 |
| 26,9 | – | 40 | ||||||||||||||
| 25 | – | 30 | 115 | 18 | 85 | 40 | 42 | 2,6 | 4 | 6 | 68 | 2 | 4 | M 12 | 14 | 1,29 |
| 33,7 | – | 45 | ||||||||||||||
| 32 | – | 38 | 140 | 18 | 100 | 42 | 52 | 2,6 | 6 | 6 | 78 | 2 | 4 | M 16 | 18 | 1,88 |
| 42,4 | – | 56 | ||||||||||||||
| 40 | – | 44,5 | 150 | 18 | 110 | 45 | 60 | 2,6 | 6 | 7 | 88 | 3 | 4 | M 16 | 18 | 2,33 |
| 48,3 | – | 64 | ||||||||||||||
| 50 | – | 57 | 165 | 20 | 125 | 48 | 72 | 2,9 | 6 | 8 | 102 | 3 | 4 | M 16 | 18 | 2,82 |
| 60,3 | – | 75 | ||||||||||||||
| 65 | 76,1 | – | 185 | 22 | 145 | 52 | 90 | 2,9 | 6 | 10 | 122 | 3 | 8 | M 16 | 18 | 3,74 |
| 80 | 88,9 | – | 200 | 24 | 160 | 58 | 105 | 3,2 | 8 | 12 | 138 | 3 | 8 | M 16 | 18 | 4,75 |
| 100 | – | 108 | 235 | 24 | 190 | 65 | 128 | 3,6 | 8 | 12 | 162 | 3 | 8 | M 20 | 22 | 6,52 |
| 114,3 | – | 134 | ||||||||||||||
| 125 | – | 133 | 270 | 26 | 220 | 68 | 155 | 4 | 8 | 12 | 188 | 3 | 8 | M 24 | 26 | 9,07 |
| 139,7 | – | 162 | ||||||||||||||
| 150 | – | 159 | 300 | 28 | 250 | 75 | 182 | 4,5 | 10 | 12 | 218 | 3 | 8 | M 24 | 26 | 11,8 |
| 168,3 | – | 192 | ||||||||||||||
| (175) | 193,7 | – | 350 | 32 | 295 | 82 | 218 | 5,6 | 10 | 15 | 260 | 3 | 12 | M 27 | 30 | 18,2 |
| 200 | 219,1 | – | 375 | 34 | 320 | 88 | 244 | 6,3 | 10 | 16 | 285 | 3 | 12 | M 27 | 30 | 21,5 |
| 250 | – | 267 | 450 | 38 | 385 | 105 | 298 | 7,1 | 12 | 18 | 345 | 3 | 12 | M 30 | 33 | 34,9 |
| 273 | – | 306 | ||||||||||||||
| 300 | 323,9 | – | 515 | 42 | 450 | 115 | 362 | 8 | 12 | 18 | 410 | 4 | 16 | M 30 | 33 | 49,7 |
| 350 | 355,6 | – | 580 | 46 | 510 | 125 | 408 | 8,8 | 12 | 20 | 465 | 4 | 16 | M 33 | 36 | 68,1 |
| – | 368 | |||||||||||||||
| 400 | 406,4 | – | 660 | 50 | 585 | 135 | 462 | 11 | 12 | 20 | 535 | 4 | 16 | M 36 | 39 | 96,5 |
| – | 419 | |||||||||||||||
| (450) | 457 | – | 685 | 50 | 610 | 135 | 500 | 12,5 | 12 | 20 | 560 | 4 | 20 | M 36 | 39 | 99,7 |
| 500 | 508 | – | 755 | 52 | 670 | 140 | 562 | 14,2 | 12 | 20 | 615 | 4 | 20 | M 39 | 42 | 117 |
DIN 2635 PN40 Weld Neck Flanges find their place in industries where high-pressure and high-temperature performance is crucial. They are frequently used in oil and gas pipelines, chemical processing facilities, power generation plants, water treatment systems, and heavy industrial machinery. Their long tapered hub provides robust reinforcement, ensuring a secure connection that can withstand demanding conditions. These flanges are essential for maintaining the integrity and efficiency of various systems, making them a go-to choice for engineers and industry professionals alike.
DIN 2635 PN40 Weld Neck Flanges are primarily used in high-pressure piping systems across industries such as oil and gas, petrochemical, power generation, and chemical processing. Their robust design ensures secure, leak-proof connections between pipes, valves, and other equipment in demanding environments exposed to high pressure, temperature, and fluctuating conditions. These flanges are commonly installed in critical systems like pipelines, reactors, compressors, and pumps, where performance and reliability are paramount. Their durability and precision make them essential for maintaining system integrity and long-term operational efficiency.
Yes, we offer custom sizes for DIN 2635 PN40 Weld Neck Flanges to meet specific project needs. Our team at Khawla Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@khawlaflanges.com.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| DIN 2635 PN40 WNRF Flanges Supplier in Muscat | Alloy Steel DIN 2635 PN40 Weld Neck Flanges Manufacturer in OMAN |
| Nickel Alloy DIN 2635 PN40 Welding Neck Flange | Mild Steel DIN 2635 PN40 Weld Neck Flange |
| 30 inch DIN 2635 PN40 Weld Neck Flange Dealer | Raised Face DIN 2635 PN40 Weld Neck Flanges Manufacturer |
| ASME SA105N Raised Faced DIN 2635 PN40 Weld Neck Flanges | 18 inch Carbon Steel DIN 2635 PN40 Weld Neck Flange |
| 18 inch DIN 2635 PN40 Carbon Steel Weld Neck Flange | DIN 2635 PN40 Weld Neck Flange Dimensions in mm |
| Alloy Steel DIN 2635 PN40 Welding Neck Flanges | Copper Nickel DIN 2635 PN40 Weld Neck Flanges at Best Price |
| DIN 2635 PN40 Welding Neck FF Flange Supplier | Suppliers of DIN 2635 PN40 Weld Neck Flange |
| DIN 2635 PN40 WNRF Flanges Distributor in Salalah | Flat Face DIN 2635 PN40 Weld Neck Flanges Exporter |
| Carbon Steel DIN 2635 PN40 Welding Neck Flange | DIN 2635 PN40 Weld Neck RF Flange Supplier |
| Raised Face DIN 2635 PN40 Weld Neck Plate Flanges | Titanium DIN 2635 PN40 Welding Neck Flanges |
| DIN 2635 PN40 WNRF Flange Stockist in OMAN | Raised Faced DIN 2635 PN40 Slip-On flanges Dealer in OMAN |
| 4 inch Stainless Steel DIN 2635 PN40 Weld Neck Flange | DIN 2635 PN40 Weld Neck RF Flanges Stockholder |
| DIN 2635 PN40 Welding Neck Flanges Supplier in Seeb | MS DIN 2635 PN40 Weld Neck Flange |
| DIN 2635 PN40 Large Diameter Weld Neck Flange | 30 Inch DIN 2635 PN40 Weld Neck Pipe Flange Dimensions |
| DIN 2635 PN40 WNRF Flange Exporter | DIN 2635 PN40 Weld Neck Flange Pressure Ratings |
| Carbon Steel Raised Face DIN 2635 PN40 Weld Neck Flange Stockist | Duplex Steel DIN 2635 PN40 WNRF Flanges Supplier in mm |
| DIN 2635 PN40 Weld Neck Pipe Flanges Wholesaler | DIN 2635 PN40 WNRF Flanges Supplier |
| DIN 2635 PN40 Weld Neck Flange Manufacturer | Flat Face DIN 2635 PN40 Weld Neck Flange Manufacturer |
| Stainless Steel DIN 2635 PN40 Weld Neck Flange | ASTM B564 Raised Faced DIN 2635 PN40 Weld Neck Flanges |
| DIN 2635 PN40 Weld Neck Flange Dimensions | Raised Face DIN 2635 PN40 Weld Neck Flange Manufacturer |
| 8 Inch DIN 2635 PN40 Welding Neck Pipe Flanges | DIN 2635 PN40 Weld Neck Flanges Stockist |
| DIN 2635 PN40 Weld Neck Pipe Flanges Supplier in Ibri | Duplex Steel DIN 2635 PN40 Weld Neck Flanges |
| German Standard DIN 2635 PN40 Weld Neck Flanges | DIN 2635 PN40 Weld Neck Flange Supplier in OMAN |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
