Khawla Flanges stands out as a top-notch manufacturer and supplier of high-quality DIN 2632 PN10 Weld Neck Flanges, proudly based in Muscat, Oman. Renowned for their precision engineering and durability, the company adheres to international standards while catering to various industries, including oil and gas, chemical processing, water treatment, power generation, and industrial piping systems. By leveraging advanced manufacturing technologies, Khawla Flanges creates flanges that guarantee robust, leak-proof connections, perfect for medium-pressure applications. With a strong focus on quality, timely delivery, and customer satisfaction, they have earned a reputation as a reliable provider of DIN 2632 PN10 Weld Neck flange solutions throughout Oman and the Gulf region.
DIN 2632 PN10 Weld Neck Flanges are generally crafted from carbon steel, stainless steel, or alloy steel, incorporating elements like carbon, manganese, chromium, nickel, and molybdenum to boost strength, corrosion resistance, and weldability. These flanges are mechanically designed to deliver impressive tensile and yield strength suitable for PN10 pressure ratings, along with excellent ductility and structural stability. The weld neck design minimizes stress concentration at the flange-to-pipe connection, ensuring dependable performance under moderate pressure and temperature conditions, making them perfect for long-lasting industrial piping applications.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
|
Germany standard flange DIN 2632 welding neck flanges; nominal pressure 10 |
||||||||||||||||
|
Brides à souder à collerette DIN 2632: pression nominale 10 |
||||||||||||||||
| Pipe | Flange | Neck | Raised face | Screws | Weight | |||||||||||
| (7,85 Kg/dm3) | ||||||||||||||||
| Rated | d1 | D | b | k | h1 | d3 | s | r | h2 | d4 | f | Holes | Thread | d2 | Kg | |
| Diameter | ISO Series | DIN Series | ||||||||||||||
| 15 | – | 20 | 95 | 14 | 65 | 35 | 30 | 2 | 4 | 6 | 45 | 2 | 4 | M 12 | 14 | 0,648 |
| 21,3 | – | 32 | ||||||||||||||
| 20 | – | 25 | 105 | 16 | 75 | 38 | 38 | 2,3 | 4 | 6 | 58 | 2 | 4 | M 12 | 14 | 0,952 |
| 26,9 | – | 40 | ||||||||||||||
| 25 | – | 30 | 115 | 16 | 85 | 38 | 42 | 2,6 | 4 | 6 | 68 | 2 | 4 | M 12 | 14 | 1,14 |
| 33,7 | – | 45 | ||||||||||||||
| 32 | – | 38 | 140 | 16 | 100 | 40 | 52 | 2,6 | 6 | 6 | 78 | 2 | 4 | M 16 | 18 | 1,69 |
| 42,4 | – | 56 | ||||||||||||||
| 40 | – | 44,5 | 150 | 16 | 110 | 42 | 60 | 2,6 | 6 | 7 | 88 | 3 | 4 | M 16 | 18 | 1,86 |
| 48,3 | – | 64 | ||||||||||||||
| 50 | – | 57 | 165 | 18 | 125 | 45 | 72 | 2,9 | 6 | 8 | 102 | 3 | 4 | M 16 | 18 | 2,53 |
| 60,3 | – | 75 | ||||||||||||||
| 65 | 76,1 | – | 185 | 18 | 145 | 45 | 90 | 2,9 | 6 | 10 | 122 | 3 | 4 | M 16 | 18 | 3,06 |
| 80 | 88,9 | – | 200 | 20 | 160 | 50 | 105 | 3,2 | 8 | 10 | 138 | 3 | 8 | M 16 | 18 | 3,7 |
| 100 | – | 108 | 220 | 20 | 180 | 52 | 125 | 3,6 | 8 | 12 | 158 | 3 | 8 | M 16 | 18 | 4,62 |
| 114,3 | – | 131 | ||||||||||||||
| 125 | – | 133 | 250 | 22 | 210 | 55 | 150 | 4 | 8 | 12 | 188 | 3 | 8 | M 16 | 18 | 6,3 |
| 139,7 | – | 156 | ||||||||||||||
| 150 | – | 159 | 285 | 22 | 240 | 55 | 175 | 4,5 | 10 | 12 | 212 | 3 | 8 | M 20 | 22 | 7,75 |
| 168,3 | – | 184 | ||||||||||||||
| 200 | 219,1 | – | 340 | 24 | 295 | 62 | 235 | 5,9 | 10 | 16 | 268 | 3 | 8 | M 20 | 22 | 11,3 |
| 250 | – | 267 | 395 | 26 | 350 | 68 | 285 | 6,3 | 12 | 16 | 320 | 3 | 12 | M 20 | 22 | 14,7 |
| 273 | – | 292 | ||||||||||||||
| 300 | 323,9 | – | 445 | 26 | 400 | 68 | 344 | 7,1 | 12 | 16 | 370 | 4 | 12 | M 20 | 22 | 17,4 |
| 350 | 355,6 | – | 505 | 26 | 460 | 68 | 385 | 7,1 | 12 | 16 | 430 | 4 | 16 | M 20 | 22 | 23,6 |
| – | 368 | 21,6 | ||||||||||||||
| 400 | 406,4 | – | 565 | 26 | 515 | 72 | 440 | 7,1 | 12 | 16 | 482 | 4 | 16 | M 24 | 26 | 28,6 |
| – | 419 | 26,2 | ||||||||||||||
| (450) | 457 | – | 615 | 28 | 565 | 72 | 488 | 7,1 | 12 | 16 | 532 | 4 | 20 | M 24 | 26 | 31,5 |
| 500 | 508 | – | 670 | 28 | 620 | 75 | 542 | 7,1 | 12 | 16 | 585 | 4 | 20 | M 24 | 26 | 38,1 |
| 600 | 610 | – | 780 | 28 | 725 | 80 | 642 | 7,1 | 12 | 18 | 685 | 5 | 20 | M 27 | 30 | 44,6 |
| 700 | 711 | – | 895 | 30 | 840 | 80 | 745 | 8 | 12 | 18 | 800 | 5 | 24 | M 27 | 30 | 62,4 |
| 800 | 813 | – | 1015 | 32 | 950 | 90 | 850 | 8 | 12 | 18 | 905 | 5 | 24 | M 30 | 33 | 84,1 |
| 900 | 914 | – | 1115 | 34 | 1050 | 95 | 950 | 10 | 12 | 20 | 1005 | 5 | 28 | M 30 | 33 | 98,5 |
| 1000 | 1016 | – | 1230 | 34 | 1160 | 95 | 1052 | 10 | 16 | 20 | 1110 | 5 | 28 | M 33 | 36 | 115 |
Khawla Flanges, a leading supplier in Muscat, OMAN, offers an extensive selection of DIN 2632 PN10 Weld Neck Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2632 PN10 Weld Neck Flanges find extensive use in medium-pressure piping systems that demand strong, leak-proof connections. They’re commonly found in water treatment plants, HVAC systems, and chemical processing pipelines. Oil and gas facilities rely on them for process lines, refineries, and auxiliary systems where dependable flange connections are crucial. Industrial plants utilize these flanges for steam, air, and fluid distribution networks. The weld neck design promotes proper alignment, reduces stress, and enhances durability, making these flanges an excellent choice for various applications.
Yes, we offer custom sizes for DIN 2632 PN10 Weld Neck Flanges to meet specific project needs. Our team at Khawla Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@khawlaflanges.com.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| 18 inch DIN 2632 PN10 Carbon Steel Weld Neck Flange | DIN 2632 PN10 Weld Neck Flange Dimensions in mm |
| Alloy Steel DIN 2632 PN10 Welding Neck Flanges | Copper Nickel DIN 2632 PN10 Weld Neck Flanges at Best Price |
| DIN 2632 PN10 Weld Neck Flange Dimensions | Raised Face DIN 2632 PN10 Weld Neck Flange Manufacturer |
| DIN 2632 PN10 Welding Neck FF Flange Supplier | Suppliers of DIN 2632 PN10 Weld Neck Flange |
| DIN 2632 PN10 Weld Neck Pipe Flanges Wholesaler | DIN 2632 PN10 WNRF Flanges Supplier |
| 30 inch DIN 2632 PN10 Weld Neck Flange Dealer | Raised Face DIN 2632 PN10 Weld Neck Flanges Manufacturer |
| Nickel Alloy DIN 2632 PN10 Welding Neck Flange | Mild Steel DIN 2632 PN10 Weld Neck Flange |
| DIN 2632 PN10 WNRF Flange Stockist in OMAN | Raised Faced DIN 2632 PN10 welding-neck flanges Dealer in OMAN |
| Raised Face DIN 2632 PN10 Weld Neck Plate Flanges | Titanium DIN 2632 PN10 Welding Neck Flanges |
| German Standard DIN 2632 PN10 Weld Neck Flanges | DIN 2632 PN10 Weld Neck Flange Supplier in OMAN |
| Stainless Steel DIN 2632 PN10 Weld Neck Flange | ASTM B564 Raised Faced DIN 2632 PN10 Weld Neck Flanges |
| DIN 2632 PN10 WNRF Flange Exporter | DIN 2632 PN10 Weld Neck Flange Pressure Ratings |
| DIN 2632 PN10 Weld Neck Flange Manufacturer | Flat Face DIN 2632 PN10 Weld Neck Flange Manufacturer |
| DIN 2632 PN10 WNRF Flanges Supplier in Muscat | Alloy Steel DIN 2632 PN10 Weld Neck Flanges Manufacturer in OMAN |
| DIN 2632 PN10 Welding Neck Flanges Supplier in Bawshar | MS DIN 2632 PN10 Weld Neck Flange |
| DIN 2632 PN10 Large Diameter Weld Neck Flange | 30 Inch DIN 2632 PN10 Weld Neck Pipe Flange Dimensions |
| Carbon Steel Raised Face DIN 2632 PN10 Weld Neck Flange Stockist | Duplex Steel DIN 2632 PN10 WNRF Flanges Supplier in Salalah |
| ASME SA105N Raised Faced DIN 2632 PN10 Weld Neck Flanges | 18 inch Carbon Steel DIN 2632 PN10 Weld Neck Flange |
| DIN 2632 PN10 WNRF Flanges Distributor in Seeb | Flat Face DIN 2632 PN10 Weld Neck Flanges Exporter |
| DIN 2632 PN10 Weld Neck Pipe Flanges Supplierin Salalah | Duplex Steel DIN 2632 PN10 Weld Neck Flanges |
| 8 Inch DIN 2632 PN10 Welding Neck Pipe Flanges | DIN 2632 PN10 Weld Neck Flanges Stockist |
| 4 inch Stainless Steel DIN 2632 PN10 Weld Neck Flange | DIN 2632 PN10 Weld Neck RF Flanges Stockholder |
| Carbon Steel DIN 2632 PN10 Welding Neck Flange | DIN 2632 PN10 Weld Neck RF Flange Supplier |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
