Khawla Flanges is a reputable manufacturer and supplier of top-notch DIN 2631 PN6 Weld Neck Flanges, proudly based in Muscat, Oman. Known for their precision engineering and reliable products, they cater to various industries, including water supply, HVAC, chemical processing, oil and gas, and general industrial operations. Utilizing cutting-edge manufacturing technologies and adhering to strict international standards, Khawla Flanges produces durable flanges designed for low-pressure piping systems. With a strong commitment to customer satisfaction, timely delivery, and competitive pricing, they have established themselves as a go-to source for DIN-standard flange solutions throughout Oman and the Gulf region.
DIN 2631 PN6 Weld Neck Flanges are generally crafted from carbon steel, stainless steel, or alloy steel, tailored to meet specific application requirements. Their composition often includes elements like carbon, manganese, silicon, chromium, nickel, and molybdenum, which boost strength, corrosion resistance, and weldability. Mechanically, these flanges provide sufficient tensile and yield strength for low-pressure systems, along with impressive ductility and structural stability. The weld neck design offers excellent reinforcement at the joint, minimizing stress concentration and ensuring a secure, leak-proof connection that’s perfect for long-term use.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Pipe | Flange | Neck | Raised face | Screws | Weight | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (7,85 Kg/dm3) | ||||||||||||||||
| Rated | d1 | D | b | k | h1 | d3 | s | r | h2 | d4 | f | Holes | Thread | d2 | Kg | |
| Diameter | ISO Series | DIN Series | ||||||||||||||
| 15 | – | 20 | 80 | 12 | 55 | 30 | 28 | 2 | 4 | 6 | 40 | 2 | 4 | M 10 | 11 | 0,392 |
| 21,3 | – | 30 | ||||||||||||||
| 20 | – | 25 | 90 | 14 | 65 | 32 | 35 | 2,3 | 4 | 6 | 50 | 2 | 4 | M 10 | 11 | 0,592 |
| 26,9 | – | 38 | ||||||||||||||
| 25 | – | 30 | 100 | 14 | 75 | 35 | 40 | 2,6 | 4 | 6 | 60 | 2 | 4 | M 10 | 11 | 0,747 |
| 33,7 | – | 42 | ||||||||||||||
| 32 | – | 38 | 120 | 14 | 90 | 35 | 50 | 2,6 | 6 | 6 | 70 | 2 | 4 | M 12 | 14 | 1,05 |
| 42,4 | – | 55 | ||||||||||||||
| 40 | – | 44,5 | 130 | 14 | 100 | 38 | 58 | 2,6 | 6 | 7 | 80 | 3 | 4 | M 12 | 14 | 1,18 |
| 48,3 | – | 62 | ||||||||||||||
| 50 | – | 57 | 140 | 14 | 110 | 38 | 70 | 2,9 | 6 | 8 | 90 | 3 | 4 | M 12 | 14 | 1,34 |
| 60,3 | – | 74 | ||||||||||||||
| 65 | 76,1 | – | 160 | 14 | 130 | 38 | 88 | 2,9 | 6 | 9 | 110 | 3 | 4 | M 12 | 14 | 1,67 |
| 80 | 88,9 | – | 190 | 16 | 150 | 42 | 102 | 3,2 | 8 | 10 | 128 | 3 | 4 | M 16 | 18 | 2,71 |
| 100 | – | 108 | 210 | 16 | 170 | 45 | 122 | 3,6 | 8 | 10 | 148 | 3 | 4 | M 16 | 18 | 3,24 |
| 114,3 | 130 | |||||||||||||||
| 125 | – | 133 | 240 | 18 | 200 | 48 | 148 | 4 | 8 | 10 | 178 | 3 | 8 | M 16 | 18 | 4,49 |
| 139,7 | – | 155 | ||||||||||||||
| 150 | – | 159 | 265 | 18 | 225 | 48 | 172 | 4,5 | 10 | 12 | 202 | 3 | 8 | M 16 | 18 | 5,15 |
| 168,3 | – | 184 | ||||||||||||||
| 200 | 219,1 | – | 320 | 20 | 280 | 55 | 236 | 5,9 | 10 | 15 | 258 | 3 | 8 | M 16 | 18 | 7,78 |
| 250 | – | 267 | 375 | 22 | 335 | 60 | 282 | 6,3 | 12 | 15 | 312 | 3 | 12 | M 16 | 18 | 10,8 |
| 273 | – | 290 | ||||||||||||||
| 300 | 323,9 | – | 440 | 22 | 395 | 62 | 342 | 7,1 | 15 | 15 | 365 | 4 | 12 | M 20 | 22 | 14 |
| 350 | 355,6 | – | 490 | 22 | 445 | 62 | 385 | 7,1 | 12 | 15 | 415 | 4 | 12 | M 20 | 22 | 18,5 |
| – | 368 | 16,7 | ||||||||||||||
| 400 | 406,4 | – | 540 | 22 | 495 | 65 | 438 | 7,1 | 12 | 15 | 465 | 4 | 16 | M 20 | 22 | 21,2 |
| – | 419 | 19 | ||||||||||||||
| 500 | 508 | – | 645 | 24 | 600 | 68 | 538 | 7,1 | 12 | 15 | 570 | 4 | 20 | M 20 | 22 | 28,6 |
| 600 | 610 | – | 755 | 24 | 705 | 70 | 640 | 7,1 | 12 | 16 | 670 | 5 | 20 | M 24 | 26 | 31,5 |
| 700 | 711 | – | 860 | 24 | 810 | 70 | 740 | 7,1 | 12 | 16 | 775 | 5 | 24 | M 24 | 26 | 37,4 |
| 800 | 813 | – | 975 | 24 | 920 | 70 | 842 | 7,1 | 12 | 16 | 880 | 5 | 24 | M 27 | 30 | 46,1 |
| 900 | 914 | – | 1075 | 26 | 1020 | 70 | 942 | 7,1 | 12 | 16 | 980 | 5 | 24 | M 27 | 30 | 55,6 |
| 1000 | 1016 | – | 1175 | 26 | 1120 | 70 | 1045 | 7,1 | 16 | 16 | 1080 | 5 | 28 | M 27 | 30 | 61,9 |
Khawla Flanges, a leading supplier in Muscat, OMAN, offers an extensive selection of DIN 2631 PN6 Weld Neck Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2631 PN6 Weld Neck Flanges find extensive use in low-pressure piping systems that demand strong, dependable, and leak-proof connections. They are frequently utilized in water distribution networks, irrigation systems, HVAC pipelines, and wastewater treatment facilities. In industrial environments, these flanges are essential for low-pressure steam, air, and fluid transfer lines. Chemical and petrochemical plants rely on them for non-corrosive and mild service pipelines. The weld neck design guarantees optimal alignment and reduces vibration, making them ideal for systems that require a long service life and stability.
Yes, we offer custom sizes for DIN 2631 PN6 Weld Neck Flanges to meet specific project needs. Our team at Khawla Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@khawlaflanges.com.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| Nickel Alloy DIN 2631 PN6 Welding Neck Flange | Mild Steel DIN 2631 PN6 Weld Neck Flange |
| Carbon Steel DIN 2631 PN6 Welding Neck Flange | DIN 2631 PN6 Weld Neck RF Flange Supplier in OMAN |
| DIN 2631 PN6 Weld Neck Flange Dimensions | Raised Face DIN 2631 PN6 Weld Neck Flange Manufacturer |
| 18 inch DIN 2631 PN6 Carbon Steel Weld Neck Flange | DIN 2631 PN6 Weld Neck Flange Dimensions in mm |
| Alloy Steel DIN 2631 PN6 Welding Neck Flanges | Copper Nickel DIN 2631 PN6 Weld Neck Flanges at Best Price |
| DIN 2631 PN6 Welding Neck FF Flange Supplier | Suppliers of DIN 2631 PN6 Weld Neck Flange |
| German Standard DIN 2631 PN6 Weld Neck Flanges | DIN 2631 PN6 Weld Neck Flange Supplier in OMAN
|
| DIN 2631 PN6 Weld Neck Flange Manufacturer | Flat Face DIN 2631 PN6 Weld Neck Flange Manufacturer |
| DIN 2631 PN6 WNRF Flange Stockist in OMAN | Raised Faced DIN 2631 PN6 welding-neck flanges Dealer in OMAN |
| Stainless Steel DIN 2631 PN6 Weld Neck Flange | ASTM B564 Raised Faced DIN 2631 PN6 Weld Neck Flanges |
| DIN 2631 PN6 WNRF Flange Exporter | DIN 2631 PN6 Weld Neck Flange Pressure Ratings |
| Raised Face DIN 2631 PN6 Weld Neck Plate Flanges | Titanium DIN 2631 PN6 Welding Neck Flanges |
| DIN 2631 PN6 WNRF Flanges Supplier in Seeb | Alloy Steel DIN 2631 PN6 Weld Neck Flanges Manufacturer in OMAN |
| DIN 2631 PN6 Weld Neck Pipe Flanges Supplier in Salalah | Duplex Steel DIN 2631 PN6 Weld Neck Flanges |
| 4 inch Stainless Steel DIN 2631 PN6 Weld Neck Flange | DIN 2631 PN6 Weld Neck RF Flanges Stockholder |
| DIN 2631 PN6 Welding Neck Flanges Supplier in Muscat | MS DIN 2631 PN6 Weld Neck Flange |
| 30 inch DIN 2631 PN6 Weld Neck Flange Dealer | Raised Face DIN 2631 PN6 Weld Neck Flanges Manufacturer |
| 8 Inch DIN 2631 PN6 Welding Neck Pipe Flanges | DIN 2631 PN6 Weld Neck Flanges Stockist |
| Carbon Steel Raised Face DIN 2631 PN6 Weld Neck Flange Stockist | Duplex Steel DIN 2631 PN6 WNRF Flanges Supplier in Muscat |
| ASME SA105N Raised Faced DIN 2631 PN6 Weld Neck Flanges | 18 inch Carbon Steel DIN 2631 PN6 Weld Neck Flange |
| DIN 2631 PN6 Weld Neck Pipe Flanges Wholesaler | DIN 2631 PN6 WNRF Flanges Supplier |
| DIN 2631 PN6 Large Diameter Weld Neck Flange | 30 Inch DIN 2631 PN6 Weld Neck Pipe Flange Dimensions |
| DIN 2631 PN6 WNRF Flanges Distributor in Muscat | Flat Face DIN 2631 PN6 Weld Neck Flanges Exporter |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
