Khawla Flanges, based in Muscat, Oman, has earned a solid reputation as a reliable manufacturer and supplier of top-notch DIN 2634 PN25 Weld Neck Flanges. These flanges are crafted to meet strict European and international standards, known for their durability and precision, making them perfect for moderate to high-pressure applications. With cutting-edge production techniques and thorough quality control, Khawla Flanges guarantees that each PN25 weld neck flange performs reliably in tough industrial environments. Supported by a skilled technical team and state-of-the-art manufacturing facilities, the company offers tailored flange solutions to meet the diverse needs of various industries, reinforcing its commitment to excellence and dependability.
DIN 2634 PN25 Weld Neck Flanges are made from high-quality carbon steel or alloy steel grades, carefully chosen to ensure they perform optimally under pressure. Their composition usually includes carbon, manganese, silicon, and specific alloying elements that boost strength, ductility, and temperature resistance. These flanges provide impressive tensile and yield strength, reliable pressure-handling capabilities, and stable mechanical performance during thermal and mechanical stress. The weld neck design allows for a smooth transition of stress, minimizing fatigue and extending service life. Each flange goes through rigorous dimensional, material, and pressure testing to meet DIN standards and ensure consistent reliability.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
|
Germany standard flange DIN 2634 welding neck flanges; nominal pressure 16 |
||||||||||||||||
|
Brides à souder à collerette DIN 2634: pression nominale 16 |
||||||||||||||||
| Pipe | Flange | Neck | Raised face | Screws | Weight | |||||||||||
| (7,85 Kg/dm3) | ||||||||||||||||
| Rated | d1 | D | b | k | h1 | d3 | s | r | h2 | d4 | f | Holes | Thread | d2 | Kg | |
| Diameter | ISO Series | DIN Series | ||||||||||||||
| 15 | – | 20 | 95 | 14 | 65 | 35 | 30 | 2 | 4 | 6 | 45 | 2 | 4 | M 12 | 14 | 0,648 |
| 21,3 | – | 32 | ||||||||||||||
| 20 | – | 25 | 105 | 16 | 75 | 38 | 38 | 2,3 | 4 | 6 | 58 | 2 | 4 | M 12 | 14 | 0,952 |
| 26,9 | – | 40 | ||||||||||||||
| 25 | – | 30 | 115 | 16 | 85 | 38 | 42 | 2,6 | 4 | 6 | 68 | 2 | 4 | M 12 | 14 | 1,14 |
| 33,7 | – | 45 | ||||||||||||||
| 32 | – | 38 | 140 | 16 | 100 | 40 | 52 | 2,6 | 6 | 6 | 78 | 2 | 4 | M 16 | 18 | 1,69 |
| 42,4 | – | 56 | ||||||||||||||
| 40 | – | 44,5 | 150 | 16 | 110 | 42 | 60 | 2,6 | 6 | 7 | 88 | 3 | 4 | M 16 | 18 | 1,86 |
| 48,3 | – | 64 | ||||||||||||||
| 50 | – | 57 | 165 | 18 | 125 | 45 | 72 | 2,9 | 6 | 8 | 102 | 3 | 4 | M 16 | 18 | 2,53 |
| 60,3 | – | 75 | ||||||||||||||
| 65 | 76,1 | – | 185 | 18 | 145 | 45 | 90 | 2,9 | 6 | 10 | 122 | 3 | 4 | M 16 | 18 | 3,06 |
| 80 | 88,9 | – | 200 | 20 | 160 | 50 | 105 | 3,2 | 8 | 10 | 138 | 3 | 8 | M 16 | 18 | 3,7 |
| 100 | – | 108 | 220 | 20 | 180 | 52 | 125 | 3,6 | 8 | 12 | 158 | 3 | 8 | M 16 | 18 | 4,62 |
| 114,3 | – | 131 | ||||||||||||||
| 125 | – | 133 | 250 | 22 | 210 | 55 | 150 | 4 | 8 | 12 | 188 | 3 | 8 | M 16 | 18 | 6,3 |
| 139,7 | – | 156 | ||||||||||||||
| 150 | – | 159 | 285 | 22 | 240 | 55 | 175 | 4,5 | 10 | 12 | 212 | 3 | 8 | M 20 | 22 | 7,75 |
| 168,3 | – | 184 | ||||||||||||||
| (175) | 193,7 | – | 315 | 24 | 270 | 60 | 210 | 5,4 | 10 | 12 | 242 | 3 | 8 | M 20 | 22 | 9,85 |
| 200 | 219,1 | – | 340 | 24 | 295 | 62 | 235 | 5,9 | 10 | 16 | 268 | 3 | 12 | M 20 | 22 | 11 |
| 250 | – | 267 | 405 | 26 | 355 | 70 | 285 | 6,3 | 12 | 16 | 320 | 3 | 12 | M 24 | 26 | 15,6 |
| 273 | – | 292 | ||||||||||||||
| 300 | 323,9 | – | 460 | 28 | 410 | 78 | 344 | 7,1 | 12 | 16 | 378 | 4 | 12 | M 24 | 26 | 22 |
| 350 | 355,6 | – | 520 | 30 | 470 | 82 | 390 | 8 | 12 | 16 | 438 | 4 | 16 | M 24 | 26 | 31,2 |
| – | 368 | 28,8 | ||||||||||||||
| 400 | 406,4 | – | 580 | 32 | 525 | 85 | 445 | 8 | 12 | 16 | 490 | 4 | 16 | M 27 | 30 | 39,3 |
| – | 419 | 36,3 | ||||||||||||||
| (450) | 457 | – | 640 | 34 | 585 | 85 | 490 | 8 | 12 | 16 | 550 | 4 | 20 | M 27 | 30 | 44,3 |
| 500 | 508 | – | 715 | 34 | 650 | 90 | 548 | 8 | 12 | 16 | 610 | 4 | 20 | M 30 | 33 | 61 |
| 600 | 610 | – | 840 | 36 | 770 | 95 | 652 | 8,8 | 12 | 18 | 725 | 5 | 20 | M 33 | 36 | 75,4 |
| 700 | 711 | – | 910 | 36 | 840 | 100 | 755 | 8,8 | 12 | 18 | 795 | 5 | 24 | M 33 | 36 | 77 |
| 800 | 813 | – | 1025 | 38 | 950 | 105 | 855 | 10 | 12 | 20 | 900 | 5 | 24 | M 36 | 39 | 101 |
| 900 | 914 | – | 1125 | 40 | 1050 | 110 | 955 | 10 | 12 | 20 | 1000 | 5 | 28 | M 36 | 39 | 122 |
| 1000 | 1016 | – | 1255 | 42 | 1170 | 120 | 1058 | 10 | 16 | 22 | 1115 | 5 | 28 | M 39 | 42 | 162 |
DIN 2634 PN25 Weld Neck Flanges find extensive use in industries that require secure, leak-proof connections for moderate to high-pressure pipeline systems. They are particularly suited for oil and gas networks, chemical processing plants, power generation facilities, water treatment systems, and various industrial machinery. The tapered hub design ensures even stress distribution, enhancing the overall integrity of the connections. These flanges are essential for maintaining safety and efficiency in critical applications, making them a preferred choice for engineers and project managers across multiple sectors.
DIN 2634 PN25 Weld Neck Flanges are used in high-pressure piping systems across industries such as oil and gas, petrochemical, power generation, and chemical processing. Their robust design ensures secure, leak-proof connections between pipes, valves, and equipment, making them ideal for applications exposed to extreme temperatures and pressures. These flanges are commonly installed in critical systems, including pipelines, pumps, compressors, and reactors, where performance, durability, and safety are paramount. Their ability to handle demanding environments ensures reliable operation and long-term system integrity.
Yes, we offer custom sizes for DIN 2634 PN25 Weld Neck Flanges to meet specific project needs. Our team at Khawla Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@khawlaflanges.com.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| Raised Face DIN 2634 PN25 Weld Neck Plate Flanges | Titanium DIN 2634 PN25 Welding Neck Flanges |
| DIN 2634 PN25 Weld Neck Flange Manufacturer | Flat Face DIN 2634 PN25 Weld Neck Flange Manufacturer |
| 30 inch DIN 2634 PN25 Weld Neck Flange Dealer | Raised Face DIN 2634 PN25 Weld Neck Flanges Manufacturer |
| DIN 2634 PN25 Weld Neck Pipe Flanges Wholesaler | DIN 2634 PN25 WNRF Flanges Supplier |
| DIN 2634 PN25 WNRF Flange Stockist in OMAN | Raised Faced DIN 2634 PN25 Slip-On flanges Dealer in OMAN |
| Alloy Steel DIN 2634 PN25 Welding Neck Flanges | Copper Nickel DIN 2634 PN25 Weld Neck Flanges at Best Price |
| DIN 2634 PN25 Welding Neck FF Flange Supplier | Suppliers of DIN 2634 PN25 Weld Neck Flange |
| DIN 2634 PN25 WNRF Flanges Distributor in Muscat | Flat Face DIN 2634 PN25 Weld Neck Flanges Exporter |
| DIN 2634 PN25 WNRF Flanges Supplier in Salalah | Alloy Steel DIN 2634 PN25 Weld Neck Flanges Manufacturer in OMAN |
| Nickel Alloy DIN 2634 PN25 Welding Neck Flange | Mild Steel DIN 2634 PN25 Weld Neck Flange |
| ASME SA105N Raised Faced DIN 2634 PN25 Weld Neck Flanges | 18 inch Carbon Steel DIN 2634 PN25 Weld Neck Flange |
| 18 inch DIN 2634 PN25 Carbon Steel Weld Neck Flange | DIN 2634 PN25 Weld Neck Flange Dimensions in mm |
| DIN 2634 PN25 Welding Neck Flanges Supplier in Seeb | MS DIN 2634 PN25 Weld Neck Flange |
| DIN 2634 PN25 Large Diameter Weld Neck Flange | 30 Inch DIN 2634 PN25 Weld Neck Pipe Flange Dimensions |
| 4 inch Stainless Steel DIN 2634 PN25 Weld Neck Flange | DIN 2634 PN25 Weld Neck RF Flanges Stockholder |
| Carbon Steel DIN 2634 PN25 Welding Neck Flange | DIN 2634 PN25 Weld Neck RF Flange Supplier |
| Carbon Steel Raised Face DIN 2634 PN25 Weld Neck Flange Stockist | Duplex Steel DIN 2634 PN25 WNRF Flanges Supplier in Muscat |
| German Standard DIN 2634 PN25 Weld Neck Flanges | DIN 2634 PN25 Weld Neck Flange Supplier in OMAN |
| 8 Inch DIN 2634 PN25 Welding Neck Pipe Flanges | DIN 2634 PN25 Weld Neck Flanges Stockist |
| DIN 2634 PN25 Weld Neck Pipe Flanges Supplier in Ibri | Duplex Steel DIN 2634 PN25 Weld Neck Flanges |
| Stainless Steel DIN 2634 PN25 Weld Neck Flange | ASTM B564 Raised Faced DIN 2634 PN25 Weld Neck Flanges |
| DIN 2634 PN25 WNRF Flange Exporter | DIN 2634 PN25 Weld Neck Flange Pressure Ratings |
| DIN 2634 PN25 Weld Neck Flange Dimensions | Raised Face DIN 2634 PN25 Weld Neck Flange Manufacturer |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
