Khawla Flanges, based in Muscat, Oman, has built a solid reputation as a manufacturer and supplier of high-performance **Incoloy 825 Flanges**. These flanges are specifically designed to tackle the tough challenges posed by corrosive and high-temperature industrial settings. With a focus on precision craftsmanship, top-notch material quality, and strict compliance with international standards, Khawla Flanges provides durable and dependable flange solutions across various sectors. Their expertise spans oil & gas, petrochemicals, marine, chemical processing, and power generation, ensuring that their Incoloy 825 Flanges deliver exceptional corrosion resistance, impressive mechanical strength, and lasting performance even in the harshest conditions.
**Incoloy 825 Flanges** are crafted from a nickel-iron-chromium alloy that’s enhanced with molybdenum, copper, and titanium. This unique blend offers remarkable resistance to sulfuric, phosphoric, and nitric acids, along with protection against chloride-induced stress corrosion cracking. On the mechanical side, Incoloy 825 boasts high tensile and yield strength, excellent thermal stability, and outstanding resistance to creep and deformation at elevated temperatures. The alloy’s well-balanced microstructure ensures reliable performance in both oxidizing and reducing environments, making Incoloy 825 flanges incredibly durable for demanding industrial applications that require long-lasting, corrosion-resistant connections.
Specifications : ASTM B564 / ASME SB564
Dimensions : ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Standard : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Size : 1/2″ (15 NB) to 48″ (1200NB)
Class/Pressure : 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
Type : Slip on flanges, Socket weld flanges, Forged flanges, Blind flanges, Welding neck flange, Ring type joint flange, Spectacle blind flange, Reducing flange, Threaded / Screwed flange, Tongue and Groove flange, Long weld neck flange, Flat flange, Industrial flanges, Plate flange, ASME B16.5 flanges.
Khawla Flanges, a leading supplier in Muscat, OMAN, offers an extensive selection of Incoloy 825 Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy 825 | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3 | 22.00 min | 38 – 46 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
**Incoloy 825 Flanges** find their place in industries where aggressive chemicals, seawater, and high temperatures are part of the daily grind. They’re perfect for chemical processing equipment, acid production facilities, offshore and marine systems, oil & gas pipelines, heat exchangers, and pollution control devices. Thanks to their excellent resistance to both oxidizing and reducing acids, they’re also well-suited for pickling equipment, scrubber systems, and chemical reactors. In the realms of power generation and desalination, these flanges play a crucial role, ensuring reliable and efficient operations in challenging environments.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 825 | 2.4858 | N08825 | NCF 825 | NA 16 | ЭП703 | NFE30C20DUM | NiCr21Mo | XH38BT |
Yes, we offer custom sizes for Incoloy 825 Flanges to meet specific project needs. Our team at Khawla Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@khawlaflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
