Khawla Flanges is a well-respected manufacturer and supplier of top-notch C22.8 Flanges located in Muscat, Oman. Renowned for their precision engineering, durability, and adherence to international standards, the company delivers reliable flange solutions to various industries, including oil and gas, petrochemicals, power generation, water treatment, and industrial piping. With state-of-the-art manufacturing facilities and rigorous quality control, Khawla Flanges creates sturdy C22.8 flanges tailored for moderate to high-pressure applications. Their dedication to product excellence, timely delivery, and customer satisfaction has established them as a trusted name across Oman and the Gulf region, making them a leading provider of dependable and efficient C22.8 flange solutions.
C22.8 Flanges are crafted from carbon steel that includes elements like carbon, manganese, phosphorus, sulfur, and silicon, which contribute to their impressive strength and weldability. This material grade boasts good tensile and yield strength, making it suitable for moderate-pressure settings. Its mechanical properties feature excellent toughness, impact resistance, and durability, ensuring reliable performance across a range of temperatures. C22.8 carbon steel guarantees structural integrity and resistance to mechanical stress, making it a perfect choice for industrial applications that demand secure sealing, consistent performance, and a long service life in challenging piping systems.
Khawla Flanges, a leading supplier in Muscat, OMAN, offers an extensive selection of C22.8 Flange, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
| Specifications | C22.8 |
| ASME B16.5 Carbon Steel C22.8 Flanges size range | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Carbon Steel C22.8 Flanges Standards | ANSI/ASME B16.5, B16.48, BS4504, B16.47 Series A & B, EN-1092, BS 10, DIN, ASME Flanges, ANSI Flanges, DIN Flanges, BS Flanges, GOST Flanges,EN Flanges |
| Carbon Steel C22.8 Flanges Standard DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| Carbon Steel C22.8 Flanges Standard ANSI | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| Carbon Steel C22.8 Flanges Standard UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Carbon Steel C22.8 Flanges Standard JIS | 5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K |
| Carbon Steel C22.8 Flanges Standard EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Main Types | Forged / Threaded / Screwed / Plate |
| Flange supporting material | Gasket, Ring Joint, Flange Bolts |
| Element / Component | Composition % |
| Carbon ( C ) | 0.18 – 0.23 |
| Manganese ( Mn ) | 0.40 – 0.90 |
| Phosphorus ( P ) | 0.035 max |
| Sulphur ( S ) | 0.030 max |
| Silicon ( Si ) | 0.40 max |
| Aluminium ( Al ) | 0.015 – 0.050 |
| Chromium ( Cr ) | 0.30 max |
| Items | Value |
| Yield Strength ReH N/mm2 | 240 min |
| Tensile Strength Rm N/mm2 | 410 – 540 |
| Elongation ( A ) | 25% min |
| Impact Test ( J ) | 44 min |
C22.8 Flanges find extensive use in industrial piping systems that require connections that are not only reliable but also durable and leak-proof. They are frequently employed in oil and gas pipelines, refinery operations, steam lines, pressure vessels, and heat exchangers. Power plants utilize them in feedwater systems, boilers, and high-temperature process lines. In water treatment and distribution networks, C22.8 flanges are essential for dependable flow control and secure pipe joints. Additionally, chemical and industrial processing facilities rely on them for fluid transport, ensuring efficiency and safety in their operations.
Yes, we offer custom sizes for C22.8 Flange to meet specific project needs. Our team at Khawla Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@khawlaflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
