EN 1092-1 Type 13 Flanges are typically crafted from carbon steel, stainless steel, or alloy steel, depending on the specific needs of the system. Their composition often includes elements like carbon, manganese, silicon, chromium, nickel, and molybdenum, which enhance their toughness, corrosion resistance, and weldability. Mechanically, these flanges boast impressive tensile and yield strength, making them ideal for low- to medium-pressure applications. They ensure stable structural integrity, excellent sealing capabilities, and durability across a range of temperatures. The design of Type 13 flanges facilitates secure connections while allowing for easy assembly and a long service life in industrial piping systems.
Khawla Flanges, a leading supplier in Muscat, OMAN, offers an extensive selection of EN 1092-1 Type 13 Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
| Size | (1/2″) To (48″) |
|---|---|
| Pressure | PN6, PN10, PN16, PN25, PN40, PN64, PN100, PN160 |
| Size Of Bore Diameter Flange | NPS ≤ 10 |
| Standard Dimensions | EN-1092, ASME B16.48, API605, BS4504, EN1092, UNI, ISO, API7S-43, ANSI/ASME B16.5, API7S-15, MSS S44, IS 2062, ASME B16.36, DIN, AWWA C207, B16.47 Series A & B, BS1560-3.1, ISO70051, API. |
| Minimum Pressure | 150# To 2500# |
| Flange Face Type Manufacturer | Raised Face, Groove And Small Tongue Groove, RTJ, Flat Face, Large Tongue & Large Male-Female And Small Male-Female, Lap-Joint Face. |
| Top Six Type Of Flange | Threaded Flange, Lap Joint Flange, Socket-Weld Flange, Blind Flange, Slip-On Flange, Weld Neck Flange |
| Standard Materials | Duplex Steel & Super Duplex Steel, Copper Nickel, Inconel, Mild Steel, Stainless Steel, Hastelloy, Alloy Steel, Carbon Steel. |
| Thickness Length | NPS ≤ 18 |
| Manufacturing Process | Forged/ Machined/ Heat Treated |
| Other Type Of Flange | Forged/ Plate/ Threaded |
| DN | GAS | Diameters | Thickness | Total | Diameter | Radius | Net | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Outside | bolt | bolt | Bolts | thickness | of the | weight | |||||
| circle | holes | Nr | Type | neck | |||||||
| D | K | L | C2 | H1 | d1 | R1 | Kg | ||||
| 15 | 1/2 | 80 | 55 | 11 | 4 | M10 | 12 | 20 | 30 | 4 | 0,43 |
| 20 | 3/4 | 90 | 65 | 11 | 4 | M10 | 14 | 24 | 40 | 4 | 0,66 |
| 25 | 1 | 100 | 75 | 11 | 4 | M10 | 14 | 24 | 50 | 4 | 0,82 |
| 32 | 1.1/4 | 120 | 90 | 14 | 4 | M12 | 14 | 26 | 60 | 6 | 1,17 |
| 40 | 1.1/2 | 130 | 100 | 14 | 4 | M12 | 14 | 26 | 70 | 6 | 1,4 |
| 50 | 2 | 140 | 110 | 14 | 4 | M12 | 14 | 28 | 80 | 6 | 1,59 |
| 65 | 2.1/2 | 160 | 130 | 14 | 4 | M12 | 14 | 32 | 100 | 6 | 2,17 |
| 80 | 3 | 190 | 150 | 18 | 4 | M16 | 16 | 34 | 110 | 8 | 3,2 |
| 100 | 4 | 210 | 170 | 18 | 4 | M16 | 16 | 40 | 130 | 8 | 3,59 |
| 125 | 5 | 240 | 200 | 18 | 8 | M16 | 18 | 44 | 160 | 8 | 4,94 |
| 150 | 6 | 265 | 225 | 18 | 8 | M16 | 18 | 44 | 185 | 10 | 5,83 |
| Rated Diameter | Flange | Neck | Raised face | Screws | Weight (7,85 Kg/dm3) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d1 | Thread | k | D | b | h1 | d3 | d4 | f | d2 | Thread | Bolt holes | KG | |
| 15 | 21,3 | R 1/2″ | 65 | 95 | 16 | 22 | 35,0 | 45,0 | 2,0 | 14 | M12 | 4 | 0,722 |
| 20 | 26,9 | R 3/4″ | 75 | 105 | 18 | 26 | 45,0 | 58,0 | 2,0 | 14 | M12 | 4 | 1,040 |
| 25 | 33,7 | R 1″ | 85 | 115 | 18 | 28 | 52,0 | 68,0 | 2,0 | 14 | M12 | 4 | 1,250 |
| 32 | 42,4 | R 1-1/4″ | 100 | 140 | 18 | 30 | 60,0 | 78,0 | 2,0 | 18 | M16 | 4 | 1,810 |
| 40 | 48,3 | R 1-1/2″ | 110 | 150 | 18 | 32 | 70,0 | 88,0 | 3,0 | 18 | M16 | 4 | 2,060 |
| 50 | 60,3 | R 2″ | 125 | 165 | 18 | 28 | 84,0 | 102,0 | 3,0 | 18 | M16 | 4 | 2,390 |
| 65 | 76,1 | R 2-1/2″ | 145 | 185 | 18 | 32 | 104,0 | 122,0 | 3,0 | 18 | M16 | 4 | 2,970 |
| 80 | 88,9 | R 3″ | 160 | 200 | 20 | 34 | 118,0 | 138,0 | 3,0 | 18 | M16 | 8 | 3,780 |
| 100 | 114,3 | R 4″ | 180 | 220 | 20 | 40 | 140,0 | 158,0 | 3,0 | 18 | M16 | 8 | 4,380 |
| 125 | 139,7 | R 5″ | 210 | 250 | 22 | 44 | 168,0 | 188,0 | 3,0 | 18 | M16 | 8 | 6,070 |
| 150 | 168,3 | R 6″ | 240 | 285 | 22 | 44 | 195,0 | 212,0 | 3,0 | 22 | M20 | 8 | 7,240 |
EN 1092-1 Type 13 Flanges find extensive use in low- to medium-pressure piping systems where secure, leak-proof connections are crucial. They’re commonly found in water supply networks, wastewater management systems, HVAC pipelines, and fire-fighting systems. In the chemical and petrochemical industries, these flanges are essential for process lines, storage tanks, and distribution piping. Industrial facilities depend on them for steam, air, and fluid transfer applications, while the oil and gas sector utilizes them in auxiliary systems and non-critical piping.
Yes, we offer custom sizes for EN 1092-1 Type 13 Flanges
to meet specific project needs. Our team at Khawla Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@khawlaflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
